Flexim FLUXUS F721 Non-Intrusive Ultrasonic Liquid Flow Measurement (Obsolete)
Enquire about this Product
This product is obsolete. Relevant documents and drawings are listed below. Please contact your local Emerson representative for your measurement needs.
- Manufacturer:
Emerson
- Valve Type:
Flexim Ultrasonic Liquid Flow Meters
- Sub-Type:
- Certified for operation within hazardous areas (ATEX/IECEx Zone 2 and FMc Class I, Division 2 certified).
- High sampling rates (output of measurement data every 10 ms), capturing pulsating flows.
- Reliable measurements of slurries or liquids with gaseous entrainments.
- High operational safety with no risk of leaks.
- Independent of pipe material, diameter, wall thickness and internal pressure and temperature.
- Accurate and repeatable measurement readings - even at extremely low flow rates (high turndown ratio).
- Highly cost-efficient in comparison to wetted instrumentation.
- Every measurement system is pre-calibrated in-house (traceable to national standards) and delivered with a calibration certificate.
- Matched transducers, integrated temperature compensation (according to ANSI/ASME MFC-5.1-2011 regulations) and advanced digital signal processing guarantee a high zero-point stability, drift-free and
- Permanent coupling ensures long-term reliable non-intrusive flow measurement even under harsh environmental conditions, such as submersion.
